Metalline Unity Rainscreen
CL1 is the vertical subframe
system suited for a wide range
of face fixed cladding applications.
CL2 is a subframe system
suitable for supporting cassettes.
CL3 is a subframe system
suitable for concealed fix/mechanically
secret fixed applications.
The CL4 is the simplistic
support system comprised of
Top Hat and Zed profiles.
A FLOOR 2 FLOOR framing system
that saves time and money on
Facade Engine is a state-of-the-art analysis tool
for all of your rainscreen subframe requirements.
This free to use software provides comprehensive
static calculations to help our customers generate
the optimum framing design.
ANALYSE | VERIFY | OPTIMISE
Made in Britain brings together the British
manufacturing community, united with the
use of the registered collective marks.
CLAD-LINE is one of the UK’s leading manufacturers of extruded aluminium non-combustible subframe systems. With over 30 years of experience in the manufacture and supply of rainscreen systems, CLAD-LINE have developed a complete set of framing solutions.
CLAD-LINE aim to simplify the design process, reduce installation time, and provide products which make everybody’s life that little bit easier. What better way is there to do this than to work in conjunction with our valued customers and draw upon their first-hand industry knowledge to develop a structurally efficient and fully compliant subframe offering.
Servicing the new build and reclad/refurb markets, the key ethos of CLAD-LINE is innovation. Our team of qualified Design Engineers help to develop innovative solutions to overcome any challenges presented by the most complicated construction projects.
With the aid of CLAD-LINE’s state-of-the-art and free to use Facade Engine software, CLAD-LINE can help any customer overcome project specific challenges and provide a comprehensive static calculation for their project requirements. A full Finite Element Analysis is also available to verify the performance of the more bespoke systems.
From the most simplistic but effective rail and bracket system to the unique Floor 2 Floor framing technology the CLAD-LINE range offers framing solutions for all design requirements and can accommodate a diverse range of cladding materials.
CL1 is CLAD-LINE’s vertical subframe system suited for a wide range of face fixed and discrete fixed cladding applications including metal rainscreen panels, fibre cement, high-pressure laminate (HPL), ACM and Rockpanel.
CL2 is CLAD-LINE’s subframe system suitable for supporting secret fixed cassette panels (Aluminium / Zinc / ACM).
CL3 is CLAD-LINE’s subframe system for mechanically secret fixed applications, suitable for use with Rockpanel, high-pressure laminate (HPL), ceramic, thin stone and fibre cement.
CL4 is CLAD-LINE’s non-combustible alternative to timber battens, comprising of Top Hat and Zed profiles which can be fixed directly back to the main structure.
Floor 2 Floor
A F2F framing system that saves time and money on installation costs, allows for maximum adjustment and reduces the need for fixings and brackets by up to 90%.
Have a question? Need more information? Would you like a CPD? We can help.
