Rainscreen Subframe System

Group 1144

CL4 is CLAD-LINE’s non-combustible alternative to timber battens, comprising of Top-Hat and Zed profiles which can be fixed directly back to the main structure. The CL4 system has been designed with oversized flanges to make fixing easier.

Suitable for rainscreens with a shallow cladding zone (25mm or 40mm), this system can be used with a wide range of face fixed cladding panels.

Features & Benefits

Suitable for use with Rockpanel, aluminium, HPL, ACM and fibre cement
Non-combustible
Ideal for new build and refurbishment
Faced fixed panel installation
Cost effective installation
Cavity range from 25mm to 40mm
100% recyclable aluminium
Powder coated or anodised finishes available on request

Technical

CL4 is CLAD-LINE’s non-combustible alternative to timber battens, comprising of Top-Hat and Zed profiles which can be fixed directly back to the main structure.

The CL4 system has been designed with oversized flanges to make fixing easier.
